The INTCERA 32GFC SFP28 optical module (GSS-MPO280-SRC) supports transmission distance up to 100m using 850nm wavelengths. Designed for 32G Fibre Channel links over duplex 850nm multimode fibers.
Features:
● Hot-pluggable SFP28 form factor
● Compliant with SFP MSA standard
● Compliant with 32GFC standard
● Single channel full-duplex transceiver module
● Supports 28Gb/s data rate
● 850nm VCSEL
● PIN photo detector
● 1W maximum power dissipation
● Maximum link length of 70m on OM3 MMF or 100m on OM4 MMF
● Duplex LC receptacles
● Operating case temperature range: 0 to 70°C
● Single 3.3V power supply
● RoHS-6 compliant (lead free)
Application:
● 8GFC
● 16GFC
● 32GFC
